Control Panel Accessories

A fire control panel (also known as a fire alarm control panel or FACP) is the central hub of a building’s fire detection and alarm system.  A fire control panel is essential for early fire detection, effective evacuation, and minimising property damage. Here’s what it does:

• Monitoring: The panel continuously monitors connected devices, such as smoke detectors, heat detectors, and manual call points, for signs of fire.
• Alerting: When a fire is detected, the panel activates alarms (e.g., sounders and strobes) to alert occupants and initiate evacuation.
• Controlling: It can activate other fire safety systems, such as smoke control systems, fire dampers, or sprinklers, to manage the fire and protect escape routes.
• Communication: The panel can send signals to emergency services or monitoring centres, ensuring a rapid response.
• Diagnostics: It provides information about the system’s status, including faults or maintenance requirements, ensuring the system remains operational.

For optimal effectiveness and compliance with UK fire safety regulations, the placement of a fire control panel is paramount. Proper placement is crucial for ensuring quick access and operation in a fire, thereby safeguarding both lives and property. Key guidelines for its location include:

• Accessibility: The panel should be easily accessible to firefighters and building managers, typically situated near the main entrance or within a secure area.
• Protection: It must be in an area shielded from fire and smoke to guarantee continued operation during an emergency.
• Clear Identification: The panel requires clear signage indicating its purpose and location, enabling rapid identification by emergency responders.
• Regulatory Compliance: Its placement must adhere to BS 5839-1:2017 (Fire Detection and Alarm Systems for Buildings) and the Regulatory Reform (Fire Safety) Order 2005.

Fire alarm control panels come in several types, each suited to different building sizes and requirements:

• Conventional Panels:Divide the building into zones. When a device is triggered, the panel indicates the zone but not the exact location.

Best for: Smaller buildings with simple layouts.

• Addressable Panels: Provide precise information about the location of the triggered device (e.g., specific room or area).

Best for: Larger or more complex buildings, such as offices, hospitals, or schools.

• Wireless Panels: Use wireless communication between devices and the panel, reducing the need for extensive wiring.

Best for: Historic buildings or sites where wiring is impractical.

• Hybrid Panels: Combine wired and wireless systems, offering flexibility for buildings with mixed requirements.

Yes. Our Control Panels include an integrated power supply with battery back-up, ensuring the smoke ventilation system remains operational during mains power failures. This is essential for life safety systems that must function in an emergency.

Yes. Manual override is a key feature of our Control Panels. Through built-in controls or remote fireman’s switches, authorised personnel and firefighters can open or close vents manually, overriding the automatic operation where necessary and appropriate.

Yes. Inbuild UK can provide technical data, wiring guidance, cause-and-effect support and product selection advice. Our goal is to help ensure the Control Panel is correctly specified, installed and commissioned in line with your project requirements and fire strategy.

The cost of a new fire alarm panel depends on several factors, including the type of panel, the size of the building, and additional features. Investing in the right fire alarm panel ensures compliance with UK fire safety regulations and protects lives and property. Here’s a breakdown:

Conventional Panels:

• Cost: £500 to £2,000.
• Best for: Small buildings with simple layouts.

Addressable Panels:

• Cost: £2,000 to £10,000+.
• Best for: Larger or more complex buildings.

Wireless Panels:

• Cost: £3,000 to £15,000+.
• Best for: Buildings where wiring is impractical.

Additional Costs:

• Installation: £1,000 to £5,000+.
• Maintenance: £100 to £500 annually.
• Upgrades: Costs vary depending on the system’s complexity.
