TOPP Chain Actuators – Detailed Installation Guide

This document provides practical fitting guidance for TOPP chain actuators, covering models C40/C40S, ACK4/ACK4S, ACK5, and C20 Series. It consolidates key points from manufacturer manuals and industry guidelines. This guide is intended as a quick reference but does not replace the official TOPP manuals, which must always be consulted before installation and operation.

C40 / C40S

Do’s – Best Practices

• Read and retain the manual as part of the device documentation.

• Use only on recommended window types (top-hung, bottom-hung) with correct mounting brackets.

• Verify voltage, stroke length (100–500 mm adjustable), and max load (400 N).

• Align chain coupling correctly: red side for top-hung, green side for vertical windows.

Don’ts – Warnings

• Do not use on unapproved frames or exceed stroke/load specifications.

• Do not install outdoors unless certified for such conditions.

Additional Notes

Ensure stroke adjustment is set correctly before commissioning.

ACK4 / ACK4S

Do’s – Best Practices

• Ensure full kit is present: actuator, brackets, template, and safety plate.

• Retain manual as part of device documentation for the lifetime of the actuator.

• If the window is accessible below 2.5 m, fit an emergency stop device.

Don’ts – Warnings

• Do not omit safety plate or protective parts.

• Do not allow installation or operation by unqualified personnel.

Additional Notes

Carry out periodic checks and ensure proper electrical protection.

ACK5

Do’s – Best Practices

• Read and preserve the manual; installation only by qualified technicians.

• Confirm actuator specifications: ~300 N thrust, selectable stroke (100–400 mm).

• Check IP55 enclosure and CE markings before installation.

• Use correct brackets and ensure precise alignment to avoid chain or motor strain.

• Engage the integrated buzzer safety feature during setup.

• Follow manual override and emergency power cut-off procedures.

Don’ts – Warnings

• Do not disregard alignment or mounting guidelines.

• Do not expose actuator to environments outside rated conditions.

• Do not attempt repairs with non-genuine parts.

Additional Notes

The ACK5 includes additional safety features compared to the ACK4, including IP55 protection.

C20 Series

Do’s – Best Practices

• Use only with TOPP-approved motors and control systems.

• Respect thrust limits and available stroke settings (e.g., 240 or 300 mm).

• Plan wiring carefully if controlling multiple actuators; consider cumulative load.

Don’ts – Warnings

• Do not exceed rated thrust capacity.

• Do not use unapproved control panels or accessories.

Additional Notes

For multiple actuator systems, follow official wiring schematics to avoid overload.

Quick Reference Table

Model	Do	Don’t
C40 / C40S	Align brackets, verify specs, adjust stroke, use only on approved windows.	Exceed load/stroke or use on unsupported frames.
ACK4 / ACK4S	Ensure full kit is installed, retain manual, fit emergency stop for low windows.	Omit safety plate or allow unqualified installation.
ACK5	Check specs, align precisely, use buzzer safety, qualified installation only.	Ignore alignment guidelines, misuse outside rated environment.
C20 Series	Use approved controls, respect stroke/thrust, plan wiring for multiple actuators.	Exceed rated capacity or use with unapproved controls.

Disclaimer

This guide has been prepared for convenience and training purposes only. It does not replace the official TOPP manuals supplied with each actuator. Installers and users must always follow the latest manufacturer’s instructions and verify compliance with local building codes, safety regulations, and professional standards. The responsibility for correct installation, operation, and maintenance rests solely with the buyer, installer, or end user.

C20 Series – Official Specifications

The C20 actuator is an articulated double-link chain actuator designed for top- and bottom-hung windows. Available in 230 V AC or 24 V DC versions, it provides reliable performance in window automation applications.

Key Specifications:

• Thrust: 300 N

• Max load: 300 N thrust / 200 N traction

• Stroke: 240 mm or 360 mm (adjustable via external knob)

• Closing stroke detection: Electronic current absorption control

• Power consumption: 0.12 A opening / 0.43 A closing

• Speed: 8 mm/s (opening), 7.5 mm/s (closing)

• Operating temperature: –5 °C to +50 °C

• Protection: IP30, double insulated

• Dimensions: 362 × 34 × 48 mm

• Weight: ~0.97 kg

Accessories and options: tandem version (two push points), bracket sets, ARS hooking device, spare parts kits.

Official Product File (PDF): https://www.topp.it/docf/TOPP-Product-File-C20.pdf

ACK4 RWA – Official Specifications

The ACK4 RWA actuator is a chain actuator designed for natural smoke and heat extraction (RWA) and ventilation in compliance with EN 12101-2. It is available in 230 V AC and 24 V DC versions.

Key Specifications:

• Thrust: 400 N

• Max traction load: 200 N

• Stroke: 300 mm or 500 mm

• Stroke selection: adjustable via external selector

• Power consumption: 0.65 A at 230 V AC, 1.5 A at 24 V DC

• Speed: ~10 mm/s

• Operating temperature: –5 °C to +65 °C

• Protection: IP55, double insulated

• Dimensions: 425 × 60 × 34 mm

• Weight: ~1.9 kg

Accessories: multiple brackets and kits available for various frame applications.

Official Product File (PDF): https://www.topp.it/docf/TOPP-Product-File-ACK4-RWA.pdf

C40 Series – Official Specifications

The C40 actuator is a double-link articulated chain actuator designed for top- and bottom-hung windows. It is available in both 230 V AC and 24 V DC versions. The C40 features a rapid chain hook system, adjustable stroke, IP55 protection, and an acoustic error warning system. A synchronous version (C40S) is also available for paired operation.

Key Specifications:

• Thrust/traction: 400 N

• Adjustable stroke: 100–500 mm (selectable via external knob)

• Current draw: 0.24 A (230 V AC), 1.1 A (24 V DC)

• Speed: 18.5 mm/s (opening), 10.5 mm/s (closing)

• Stroke duration: 27 s (opening), 48 s (closing)

• Duty rating: S2 of 5 min (230 V) / S2 of 8 min (24 V)

• Operating range: –5 °C to +50 °C

• Protection: IP55, double insulated

• Sync capability: Yes, available in C40S version

• Error warning: Integrated acoustic buzzer

• Dimensions: 388 × 50 × 95 mm

• Weight: approx. 1.9 kg

Accessories: swivel frontal brackets for various window types, upper bottom-hung brackets, ARS rapid hooking device, spare parts catalog, available in multiple colors.

Official Product File (PDF): https://www.topp.it/docf/TOPP-Product-File-C40.pdf

ACK4 Series – Official Specifications

The ACK4 actuator is a compact, high-performance chain actuator widely used in window automation. It is designed for top- and bottom-hung windows, and is available in both 230 V AC and 24 V DC versions. The ACK4 is equipped with IP55 protection (IP66 variant available) and features an acoustic buzzer to indicate incorrect installation. A synchronous (ACK4S) version is also available for paired operation.

Key Specifications:

• Thrust: 300 N

• Stroke: up to 400 mm, adjustable via external knob

• Power supply: 230 V AC (0.32 A), 24 V DC (1.35 A)

• Speed: 27 mm/s (230 V), 17 mm/s (24 V)

• Stroke duration: ~15 s (230 V), ~23 s (24 V)

• Operating temperature: –5 °C to +50 °C

• Protection: IP55 standard, IP66 optional

• Insulation: Double insulated, CE-marked

• Sync capability: Yes, synchronous version available (ACK4S)

• Error warning: Acoustic buzzer included

• Dimensions: 288.5 × 83 × 47.8 mm
